Single Disc Wedge Gate Valve

Single disc wedge gate valves feature a simple and robust design, making them ideal for applications requiring reliable shutoff and minimal maintenance. The wedge-shaped gate ensures a tight seal against the valve seat, preventing leakage and ensuring long-term performance. Single disc wedge gate valves find widespread use in water distribution systems, fire protection systems, and industrial processing plants, where dependable operation and ease of maintenance are critical for system integrity and safety.

+86 17357466831

lip@lipvalve.com

Design Advantages

Simple Design: Featuring a single disc wedge design, this valve offers straightforward operation and reliable sealing for fluid control applications.

Efficient Flow Regulation: The wedge-shaped disc provides precise modulation of fluid flow, ensuring optimal performance in various industrial processes.

Tight Sealing: The wedge gate mechanism ensures tight sealing to prevent leakage and maintain system integrity during operation.

Durable Construction: Constructed with high-quality materials, the valve withstands harsh operating conditions for long-term reliability.

Wide Range of Applications: Suitable for use in water treatment, oil and gas, power generation, and other industries requiring efficient flow control.

Cost-Effective Solution: Provides a cost-effective solution for fluid control applications, offering reliable performance and minimal maintenance requirements.

Technical Parameters

Size	DN15-DN2000, 1/2''-80''
Pressure	PN10-PN420, Class150-Class2500
Temperature	-200℃ to 650℃
Connection type	Flange, Thread, Socket weld, Butt weld
Operation mode	Manual, Pneumatic, Electric, Hydraulic, Gear transmission

Materials

Valve Body	Forged	A105, LF2, F5, F9, F11, F22, F304, F316, F347, F904, F51, F53, F310, N08020, Inconel625, etc
	Cast	WCB, LCB, C5, C12, WC6, WC9, CF8, CF8M, CF8C, 4A, 5A, CN7M, C95800, CW6MC, etc
Valve Stem		F6a, 17-4PH, XM-19, F304, F316, F347, F904, F51, F53, F310, Monel400, Monel500, N08020, Inconel625, Incoloy825，etc
Valve Disc		A105, LF2, F5, F9, F11, F22, F304, F316, F347, F904, F51, F53, F310, N08020, Inconel625, F6a, 17-4PH, XM-19, F304, F316, F347, F904, F51, F53, F310, Monel400, Monel500，Incoloy825，WCB, LCB, C5, C12, WC6, WC9, CF8, CF8M, CF8C, 4A, 5A, CN7M, C95800, CW6MC, etc
Seat Sealing		SS,BR,CU,AS,CS,AL,PTFE,NBR,FKM,AI203,etc

Design Standards

Valve Body	API 600, API 602, ASME B16.34, DIN 3352, BS 5163, GOST 5762, JIS B2073, GB/T 12233, etc.
Flange	ANSI B16.34, EN 1982, JIS B2210, GB/T 17241, ASME B16.42, GOST 12815, DIN 3202-1, etc.
Connection	ANSI B16.10, ASME B16.25, JIS B2212, GOST 33259, DIN 3202, etc.
Test Standards	API 598, ISO 5208, BS EN 12266, ASME B16.104, GOST 9544-2015, JIS B2003, DIN 3230, etc.

The careful selection of design standards for Single Disc Wedge Gate Valve is crucial to ensure adherence to international quality and safety benchmarks. By complying with these standards, Single Disc Wedge Gate Valve offer outstanding performance, longevity, and suitability across various installations and applications.
