Why do you choose Lipin Concentric Butterfly Valves

Regarding excellent fluid control, Lipin is a reliable brand in the industry, especially for the concentric butterfly valve. The following is a diving of why the concentric butterfly valve of Lipin is a prudent choice.

Unique simplicity

The goal of Lipin concentric butterfly valve is to achieve consistent matching of valve plate, shaft and valve body axis. This symmetry is important for ensuring a consistent and reliable seal, maintaining even pressure and minimizing wear.
Quality materials

In addition to traditional carbon steel, Lipin also offers stainless steel and duplex stainless steel to increase elasticity against corrosive corrosion.
Strive for excellence

Lipin manufactures valves to strict standards, in compliance with ASME 150 and 300 benchmarks.
Efficient Flow Control

Our concentric butterfly valve is widely used for liquid flow control due to its cost-effectiveness. It’s easy to operate, maintain, and offers long-lasting performance.
Simple Central Design

The valve's stem is centrally located, with a disc positioned in the middle of the valve. This simple structure ensures reliable flow control and easy handling.
Lightweight and Durable

The valve is lightweight, making it practical for various uses. Its components are durable and comparable to other high-quality flow control systems.

Key Components of Concentric Butterfly Valves

The Concentric Butterfly Valves mainly consists of the following nine parts. This component ensures that the Butterfly valve remains efficient and stable during operation and maintains a zero leakage record.

Body

Defines the fluid's route.

Disc

Central regulator of fluid flow.

Stem

Rotates the disc in alignment with the body.

Seat

Ensures tight sealing against leaks.

Actuator

Drives the valve's movement.

Seals

Counter internal fluid leaks.

Retaining Ring

Anchors the disc to the stem.

Central Bushing

Provides stability and alignment.

Bearings

Aid in smooth valve rotation.

Advantages of

Concentric Butterfly Valves

01

They take up less space than other valves

They take up less space than other valves.
02

Due to its compact and lightweight form

Due to its compact and lightweight form, installation, maintenance and labor costs are reduced.
03

Because the seat is constructed

Because the seat is constructed as a sleeve or spool inside the valve body, the medium flowing through the valve does not touch the valve body.
04

Concentric butterfly valves are easier to install

Concentric butterfly valves are easier to install.
05

A variety of seat and disc

A variety of seat and disc materials are available for different industrial applications.
06

These valves require

These valves require less support to close than industrial ball valves.

Why Opt for Concentric Butterfly Valves?

The concentric butterfly valve has a simple structure and is composed of fewer components, making it easier to operate and maintain. The valve adopts full diameter structure to regulate the flow rate and ensure the smooth passage of fluid.

About Lipin Concentric Butterfly Valve

Body Type:

Concentric
Body Materials:

Cast Iron (for general applications), 316 stainless steel, and brass (for specific corrosion resistance applications), etc.
Stem Material:

Typically constructed of brass or a material compatible with the body to ensure no galvanic corrosion occurs.
Seat Material:

EPDM (Ethylene Propylene Diene Monomer), NBR (Nitrile Butadiene Rubber), Neoprene
Disc Material:

Generally made of ductile iron, stainless steel, or bronze, with potential coatings based on specialized applications.
Bearings:

Frequently fabricated from bronze or nylon for durability and to ensure minimal friction during operation.
Pressure Ratings:

Class 125-1500 (based on ASME standards) Or PN6~PN100
Actuators:

Manual lever, gearbox, electric actuator, hydraulic actuator
Size:

Available from 1/2''-48'' (DN15-DN1200)
Temperature:

Depends on materials used, but typically, EPDM seats can accommodate temperatures from -40°C to +135°C, with variations possible with specific materials.

About the Application of

Lipin Concentric Butterfly Valve

Concentric butterfly valves, owing to their simplistic yet effective design, ensure uniform pressure distribution and seal tightness. These unique characteristics render them especially apt for particular industrial applications.

Oil and Gas Industry
Chemical Industry
Steam Systems
Pharmaceutical Manufacturing
Water Management and Supply
Construction Sector
Energy Industry
Water Treatment
