Bonnet Bolted Gate Valve

Reliable Fluid Control
Introducing Lipin's Bonnet Bolted Gate Valves

Lipin excels with its superior bonnet bolted gate valves, crafted for diverse industrial applications, particularly in the oil and gas sector. These valves, ranging from 1/2" to 60" (DN 15-1500), are designed for robust performance with a focus on safety and durability. Adhering to ANSI/ASME B16.34 standards, they feature a bonnet bolted design, ensuring secure sealing and long-term reliability. Material options include carbon steel for general use and 316 or duplex stainless steel for corrosion resistance. Lipin's commitment to quality ensures these gate valves provide optimal flow control and system integrity.

Why Choose Lipin's Bonnet Bolted Gate Valve

Lipin's bonnet bolted gate valves stand as a benchmark in the valve industry, especially for critical applications like oil and gas. Here's why they are a preferred choice:

Robust Sealing

The bonnet bolted design ensures a secure and reliable seal, reducing leakage risks and enhancing operational safety, crucial for high-pressure environments.
Material Excellence

Lipin provides these valves in various materials, including standard carbon steel for durability and stainless steel options for superior corrosion resistance, catering to diverse industrial needs
Versatile Applications

From oil and gas extraction to water treatment, these gate valves demonstrate unmatched versatility, suitable for a wide range of temperatures and pressures.
Compliance with Standards

Adhering to ASME 150 and 300 standards, Lipin's valves are synonymous with quality and longevity, built to withstand the demands of rigorous industrial use.
Dedicated Support

Lipin's commitment to customer satisfaction extends beyond sales, offering comprehensive support and maintenance, ensuring long-term reliability and performance.

Key Components of Bonnet Bolted Gate Valve

The Bonnet Bolted Gate Valve mainly consists of the following nine parts. This component ensures that the gate valve remains efficient and stable during operation and maintains a zero leakage record.

Valve Body

The foundational structure that encapsulates the valve's internal mechanisms.

Gate

The primary flow control element, moving vertically to regulate fluid passage.

Stem

Connects the gate to the actuator, translating rotational or linear motion.

Sealing Surface

Ensures a tight closure with the gate, preventing leaks.

Actuator

Can be manual, electric, or pneumatic, enabling gate movement.

Gaskets

Ensure a leak-proof seal between the bonnet and valve body.

Flow Direction Indicator

Marks the correct installation orientation for optimal operation.

Packing

Provides a seal around the stem to prevent external leaks.

Bonnet

Secures the top of the valve body, incorporating the stem and packing.

Why Choose Bonnet Bolted Gate Valve?

Opting for bonnet bolted gate valves means investing in reliability, efficiency, and durability. Their specialized design ensures secure sealing and effective flow control, making them a prudent choice for maintaining system integrity across various industrial sectors. Their resilience under pressure and ease of maintenance make them a cost-effective and reliable solution for long-term industrial use.

About Lipin Bonnet Bolted Gate Valve

Body Type:

Robust, Traditional Design
Body Materials:

Carbon steel for standard needs, 316 stainless steel, and duplex stainless steel for higher corrosion resistance.
Seat Material:

Often metal or soft-seated, featuring resilient materials like PTFE or EPDM to ensure reliable sealing.
Disc Material:

Durable stainless steel or other suitable materials, depending on the application.
Pressure Ratings:

Ranges from Class 150 to Class 2500, following ASME standards.
Actuators:

Options include manual handwheels, gears, or motorized actuators for automated control.
Temperature:

Capable of handling a broad range from -29°C to over 500°C, depending on material choice.
Size:

Available in sizes from 2'' to 48'' (DN50-DN1200), accommodating a wide range of pipeline requirements.

Lipin Bonnet Bolted Gate Valve

Lipin's bonnet bolted gate valves excel with their robust design and versatile application, making them crucial in sectors where precise flow control and durability are essential.

Oil and Gas Industry
Chemical Industry
Steam Systems
Pharmaceutical Manufacturing
Water Management and Supply
Construction Sector
Energy Industry
Water Treatment
